| Modèle N°.: | ZD-GALWIRE | Application du projet: | Corde, empaquetant, prenant au filet, fabrication, clôturant, construction |
|---|---|---|---|
| Alliage ou non: | Fabriqué sur mesure | La norme: | LES BS, JIS, GIGAOCTET, ASTM, DIN, AISI |
| Matériel: | Pour les pièces détachées, les caractéristiques suivantes doivent être indiquées: | Fabriqué sur mesure: | Je suis désolé. |
| Cycle personnalisé: | 7 à 15 jours | Nom du produit: | Fil d'acier galvanisé |
| Délai de paiement: | 30% T/T d'avance + 70% de solde | Nombre de pièces: | 3 tonnes |
| Longueur: | Fabriqué sur mesure | Avantages: | Résistance à l'usure, usinabilité, soudage facile |
| Spécification2: | - Je ne sais pas. | Spécification3: | - Il y en a une autre. |
| La norme 1: | Pour les produits à base de plantes, le produit doit être présenté sous forme d'une couche d'étiquet | Paquet de transport: | Paquet type d'exportation/à la demande |
| Spécification: | Conformément aux exigences du client | Marque déposée: | Zhengde |
| Origine: | Chine | Code du SH: | 7217200000 |
| Capacité d'approvisionnement: | 50000 tonnes par mois | ||
| Mettre en évidence: | fil d'acier galvanisé 0,7 mm,fils d'acier galvanisé 0 |
||
ZHENGDE Galvanized wire production process: It is processed by high-quality low-carbon steel wire rod, and the high-quality low-carbon steel is processed by drawing forming, pickling and derusting, high-temperature annealing, hot-dip galvanizing and cooling.
Galvanized wire characteristics: Galvanized iron wire has good toughness and elasticity, and the highest amount of zinc can reach 300 grams per square meter. It has the characteristics of thick galvanized layer and strong corrosion resistance.
Galvanized wire application: The products are widely used in various fields such as construction, handicrafts, weaving wire mesh, highway guardrails, product packaging and daily civilian use.
Galvanized wire is further divided into hot-dip galvanized wire and cold-dip galvanized wire (electro-galvanized wire), which are distinguished as follows:
Hot-dip galvanizing is dip-plating in a heated and melted zinc solution. The production speed is fast, and the coating is thick but uneven. The minimum thickness allowed by the market is 45 microns, and the maximum thickness can reach more than 300 microns. The color is darker, consumes more zinc metal, forms an infiltration layer with the base metal, and has good corrosion resistance. Hot-dip galvanizing can last for decades in outdoor environments.
Cold galvanizing (electrogalvanizing) is to gradually coat the metal surface with zinc through the unidirectional current in the electroplating tank. The production speed is slow, the coating is uniform, and the thickness is thin, usually only 3-15 microns. The appearance is bright and the corrosion resistance is poor. It usually rusts in a few months.
Compared with hot-dip galvanizing, the production cost of electro-galvanizing is lower.
| Gauge | SWG | BWG | AWG | Metric system | ||||
| in | mm | in | mm | in | mm | mm | kg/km | |
| 0 | 0.324 | 8.23 | ||||||
| 1 | 0.3 | 7.02 | ||||||
| 2 | 0.276 | 7.01 | ||||||
| 3 | 0.252 | 6.401 | 0.259 | 6.58 | 0.2294 | 5.83 | ||
| 4 | 0.232 | 5.893 | 0.238 | 6.05 | 0.2043 | 5.19 | 6 | 220 |
| 5 | 0.212 | 5.385 | 0.22 | 5.59 | 0.1819 | 4.62 | 5.5 | 185 |
| 6 | 0.192 | 4.811 | 0.203 | 5.16 | 0.162 | 4.11 | 5 | 153 |
| 7 | 0.176 | 4.47 | 0.18 | 4.57 | 0.1443 | 3.67 | 4.5 | 124 |
| 8 | 0.16 | 4.064 | 0.165 | 4.19 | 0.1285 | 3.26 | 4 | 98 |
| 9 | 0.144 | 3.658 | 0.148 | 3.76 | 0.1144 | 2.91 | 3.5 | 95 |
| 10 | 0.128 | 3.251 | 0.134 | 3.4 | 0.1019 | 2.59 | 3.2 | 62 |
| 11 | 0.116 | 2.946 | 0.12 | 3.05 | 0.09074 | 2.3 | 2.9 | 51 |
| 12 | 0.104 | 2.642 | 0.109 | 2.77 | 0.08081 | 2.05 | 2.6 | 41 |
| 13 | 0.092 | 2.337 | 0.095 | 2.41 | 0.07196 | 1.83 | 2.3 | 32 |
| 14 | 0.08 | 2.032 | 0.083 | 2.11 | 0.06408 | 1.63 | 2 | 24 |
| 15 | 0.072 | 1.829 | 0.072 | 1.83 | 0.05707 | 1.45 | 1.8 | 20 |
| 16 | 0.064 | 1.626 | 0.065 | 1.65 | 0.05082 | 1.29 | 1.6 | 16 |
| 17 | 0.056 | 1.422 | 0.058 | 1.47 | 0.04526 | 1.15 | 1.4 | 12 |
| 18 | 0.048 | 1.219 | 0.049 | 1.24 | 0.0403 | 1.02 | 1.2 | 8 |
| 19 | 0.04 | 1.016 | 0.042 | 1.07 | 0.03589 | 0.91 | 1 | 6 |
| 20 | 0.036 | 0.914 | 0.035 | 0.89 | 0.03196 | 0.812 | 0.9 | 5 |
| 21 | 0.032 | 0.873 | 0.032 | 0.81 | 0.02846 | 0.723 | 0.711 | 3.2 |
| 22 | 0.028 | 0.711 | 0.028 | 0.71 | 0.02535 | 0.644 | 0.558 | 3.1 |
Shandong Zhengde Metal Manufacturing Co., Ltd. is a production and sales company integrating hot-rolled steel coils, cold-rolled steel coils, galvanized steel coils, color-coated steel coils, section steel, steel pipes, steel wires, metal mesh, stainless steel, aluminum, copper and other metal products integrated large enterprises. Five production and sales bases have been formed in Binzhou, Liaocheng, Wuxi, Tianjin, Jinan and Tai'an, with more than 100 production lines, 4 nationally recognized laboratories, 2 technical engineering centers, and 5 enterprise technology centers. Products are exported to more than 50 countries and regions such as North America, South America, Europe, Middle East region, Russia, Africa, North America, and other parts of the world.
